Power: 22kW
Charge:
Installation:
Protection: ΙΡ55, ΙΚ10
User authentication:
|
AC Input Characteristics
|
AC input voltage | 400VAC ± 10% |
| Input type | 3P + N + PE | |
| AC Input Curren | 32Α / φάση | |
| Frequency | 50Ηz | |
|
AC Output Characteristics
|
AC Output Voltage | 400VAC |
| Power | 22 kW maximum | |
| AC Output Current | 32 A / phase | |
|
Ambient Conditions
|
Operating temperature | -25°C – 50°C |
| Storage temperature | -30°C – 70°C | |
| Humidity | 5% – 95% RH (without condensation) | |
| Installation Altitude | Up to 2000m | |
|
Construction
|
Enclosure | Sheet Metal, Polycarbonate* |
| IP rating | ΙΡ55 | |
| IK rating | ΙΚ10 | |
| Display | LCD 4,3” | |
| Outputs | Τype 2 socket outlet or tethered cable 5m length with Type 2 outlet | |
| Charger Dimensions | 350x162x1508mm | |
|
Electrical Parts
|
Energy Meter | 3-phase MID energy |
|
Protective devices
|
Residual Current Protection RCD Type B | |
|
Surge Protection SPD Type 2
|
||
| Micro Circuit Breaker 4P Type C | ||
| Ground Loss Detection | ||
| Over Temperature Protection (OTP) | ||
| Communication Protocol | S2W & OCPP 1.6 JSON | |
| Language Menu | Greek, English | |
| User Authentication | RFID | |
| Connectivity | WIFI and Ethernet or GSM | |
|
Charging Installation
|
Circuit-Breaker Protection | Grid MCB Type B 4P |
| 3-phase Phase Grid Power Supply | 25kVA –Level 2** | |
| ATEX | ΕInstallation outside ATEX zones | |
| Grid Substation | Not applicable | |
| Cable Cross Section | 5x10mm2 (cable length up to 120m) 5x16mm2 (cable length > 120m) | |
|
Certification
|
EN regulations | IEC EN 61851-1:2017 IEC 61851-21-2:2018 EN 62196-1:2014 EN 62196-2:2016 |
| Accredited Certification Body | DEKRA | |
| Warranty | 2 years |
*Capability to have anti-graffiti paint or different paint and stickers (branding capability) on the enclosure (after order).
** The level of the grid power supply should be calculated each time according to the power consumption of the installation, adding the load of the
charger and taking into consideration the coefficient factor. Minimum level of power supply to cover the needs of the charger 25kVA – Level 2 of Grid
Operator’s power supplies.
